My Jodel ZK-EDR outside Gate 19 Wellington International Airport back in Christmas  2009.



                                                  Some Jodel History and Spec,s

Country of origin:

France

Description:

Two-seat dual-control low-wing touring monoplane

Power Plant:

One 67 kw (90 hp) Rolls Royce/Continental O-200-A four-cylinder horizontally-opposed air-cooled engine

Specifications:

• Wingspan: 8.23 m (27 ft)
• Length: 6.46 m (21 ft 2 in)
• Wing area: 12.72 m² (137 sq ft)
• Never exceed speed: 249 km/h (155 mph)
• Max speed: 209 km/h (130 mph)
• Cruising speed: 209 km/h (118 mph)
• Landing speed: 80 km/h (50 mph)
• Stalling speed: 56 km/h (35 mph)
• Initial rate of climb: 244 m/min (800 ft/min)
• Ceiling: 5,182 m (17,000 ft)
• Take-off run: 137 m (450 ft)
• Landing run: 137 m (450 ft)
• Range: 1,151 km (715 miles)
• Fuel capacity: 100 litres (22 Imp gals)
• Power loading: 15 lb/hp
• Wing loading: 9.9 lb/sq ft
• Empty weight: 318 kg (700 lb)
• Useful load: 287 kg (632 lb)
• Loaded weight: 617 kg (1,360 lb)

History:

Designed as a two-seat development of the Jodel D-9, the D-11 became the basic model in a series of Jodel two-seat, light aircraft designs for amateur and commercial production. Excellent flying qualities established the type as the most popular French two-seater, and the handling qualities led to its adoption for some years as the standard training aircraft among French flying clubs.

The D-11 was essentially of simple but rugged construction. The one-piece cantilever wing had upswept, tapered outer panels, typical of most Jodel designs, with the inboard part of the wing being straight and flat. In other respects the construction was conventional using spruce and plywood with fabric covering. The wing was built on a single box-spar, which also supported the two legs of the wide track undercarriage. The undercarriage employed rubber in compression springing, and was fitted with light industrial wheels. The fuselage was of rectangular box structure with a curved spruce top decking and plywood covering. The tail was also plywood covered, while the elevator and rudder were fabric covered. Power plants ranging from 48 kw (65 hp) to 81 kw (108 hp) could be fitted, but the very popular Continental O-200 series was usually installed.

At one stage the Jodel D-11 was the most popular aircraft for amateur construction in this region, with over 20 completed in Australia and 30 in New Zealand. However, in numbers it has been well and truly overtaken by such modern types as the Stoddard Hamilton Glasair, Neico Lancair, Vans RV-4 and RV-6, etc.

In Canada the design of the D-11 was modified by Falconar Aircraft, these being known as the F-11A Sporty and the F-12A Cruiser. These had swept tail surfaces and could be fitted with engines up to 104 kw (140 hp), and folding wings. Examples of the Falconar models have been completed in New Zealand, an F-11A becoming ZK-KEA (c/n AACA/490) and an F-12 becoming ZK-DBI (c/n AACA/102) in November 1975. In Australia one of the first Falconar F-12As became VH-PKQ (c/n F8243) in November 2004

                             Couple JODEL happenings noted of late.

                        Photo credit goes to SAA Magazine,

Some news from Jodel Central TOKOROA. Karl B has been busy rebuilding 0200,s of late. Looking dam fine nice work.

Tony A has been busy with the re engine of  D-18 ZK-OWL having biffed the E81 out and fitting a AeroVee VW derived power plant in. New engine mount shown here.

Bruce C has been busy getting used to his new ride Jodel D18 ZK-JAC. He reports fitting of a new brake system so should all good to go once completing his rating.

Now up for sale is Jodel D11 ZK-DYB ex Graham French built machine based currently outa NZPP.

Having Flown this back in the day Thanks Graham it was a hoot.

Get in quick.

Harry and RSB were in for a bit he was on a super secret mission for the Man.

I suspect bit Muddy at Kaipara Flats and here.



The sad news of the passing of one NZ,s greatest aviators

BRETT EMENY

I heard Yesterday what an absolute BUMMER.

BRETT gave me my rating in the Jodel EDR which I must say was an absolute Hoot. We did it at NZNP the usual stuff stalls, FLWOP, EFATO ETC. He said right ya passed now I will show ya what ya can really do in a Jodel and he did using the Grass 05/23 runway outside the Terminal we zipped Backwards and Forwards in both directions on one wheel then the other steep approaches etc. I would have loved to have been in the Terminal watching all this going on must have been interesting .......

So long Chap fair winds always.



Great shot of KCD on her way up into the wild Blue.

Can,t remember who I stole pic from. Thanks.





Spotted KEA at Hawera on Sat when down for the Fly-in at HAWERA on the Saturday.

On passing the Airfield on Monday there she was all on her lonesome so took the time to get some pic,s.

Typical day after Fly-in it was beautiful I mean look at that sky.

Kea hails from Waikanae I suspect hangered at one of the local Aerodromes.

KEA is Falconair D11 { Canadian version of the Jodel D11} according to CAA.

It has bent wings so there.

Popped in briefly (Tue) and these fella,s turned up. Now if ya wanna get into the Ag stuff they are looking for a Loader Driver at the Mo as young Tony is Retiring after a Job well done (do it myself but me right Flipper ain,t up to speed BUGGER) That,s Tony there in his Striking Yellow Shirt.

TRADEME ADD.

Aircraft Loader Driver - Stratford | Trade Me Jobs

Local Aerodrome Hawk doing his thing very Majestic.
